VSVTS Products
Features
GPS Tracking
Geo-fence alerts
Speed & Speed Violation
Distance travelled
Location capture
Overstay violation
Automated Trips
Internal Storage
Analog Inputs & Digital I/O
OTA Enabled
Route planning & Management
| Dimensions | 76mm (Length) x 72mm (Width) x 31mm (Height) |
| Weight | 0.35Kg (approx.) |
| Network | GSM/GPRS |
| GSM Band | Quad Band 850/900/1800/1900 MHz |
| Position Acquiring Method | GPS+GLONASS |
| Receiver type | 33 tracking / 99 acquisition/210 PRN – channels GPS – L1 Band Receiver (1575.42MHz) GLONASS – L1 Band Receiver (1601.71MHz) |
| Position sensitivity Acquisition (Cold Start) Tracking Re-Acquisition |
-149 dBm -167 dBm -161 dBm |
| Horizontal Position accuracy – Autonomous | <2.5-meter CEP @-130dBm |
| Position acquiring start time | Hot Start : 1s (Typical) Warm Start : <30s (Typical) Cold Start : <35s (Typical) |
| Velocity Accuracy | Without Aid – 0.1 m/S |
| Acceleration Accuracy | Without Aid – 0.1 m/S² |
| Input Power supply | 9 to 36V |
| Input current | 90ma (Normal operation) @12V 130mA (Upload Time) @12V 20mA@12V (Automatic sleep mode on IGN OFF (saves power) |
| Voltage Protection | Over Spike Voltage, Over current, reverse voltage and short circuit |
| Internal Battery Capacity | 3.7V, 2200mAH |
| Internal Power Backup up to | 26Hrs – 10sec upload time (not final value, testing is still in progress) |
| LED Indication | Power, GSM, GPS and Charge |
| Memory storage | 16GB micro SD card / more than 4yrs records storage |
| IO Interface | 2 Digital Input Channels 1 Digital output Channels |
| Storage Temperature | -40⁰C to + 75⁰C |
| Operating Temperature | -20⁰C to + 65⁰C |
| Humidity | 5% – 95% Non-Condensing |
| IP Rating | IP67 (Water Proof – 1m deep into water for 30 minutes) |
| Vibration | Random – 5Hz to 500Hz, 20hrs, 3 Axes; |
| Sine wave – Log sweep from10Hz to 2000Hz, 5g peak | |
| Accelerometer | 3-Axis Output Resolution Auto-Normalization |
| Over The Air firmware upgrade | Available |
| Remote configuration | SMS/Web server configuration |
| Data Encryption | Available – End to End data Encryption |
| Sleep Mode | Available |
| Data upload interval | Configurable through SMS, between 10Secs to 60Mins |
| Driving pattern detection | Harsh braking and rash driving can be detected |
| Standards Compliance | ISO 7637 – 2 & ISO 16750 -2 |
- Real-time location tracking with GPS
- Enhanced safety & security
- Simple Installation process
- 7-year data retention
- Highly accurate (5 meters accuracy)
- View live traffic of your fleet
- History tracking and analytics
- Secure and encrypted communication
- Alerts through SMS, mobile app and web
- Integration with Backend ERPs – if any
- Enable auto trips based on defined location
- Tracking for multiple vehicles / multiple devices
- Data integration in AWS cloud for critical alert notifications
- Geo fencing enabled, Auto Geo-fencing facility
- Share vehicle trips with password to Transporters/Owners
- Route plan, automated mapping and route violation analysis
- Freight Bills Generation and reconciliation
- Real-time tracking with analytical and MIS Reports
- Capture trip distance travelled / Mapped locations stay period
- Capture Speed violations and stay duration violations
- SaaS platform. Includes software, hardware, licensing and support
Logistics and Supply chain, School vans/buses, Cars and Bikes (without health monitoring), Mass transport
